Live Broadcast 2.2 Megapixel Video Surveillance 3G / HDSDI Lipstick Camera 1080P 60/50fps

Broadcast Video Surveillance 2.0 Magapixe Micro Bulletl HD SDI Camera With RS485

SDI stands for “serial digital interface",HD-SDI is a new technology offering full High Definition 1080p picture over coaxial cable, SDI is a standard used for the transmission of digital video signals over a coaxial cable,be run long distances without video loss,It can offer real-time and un-compressed broadcasting video quality, up to 1080p / 2.2 MP resolution.SDI technology has been in existence in the media TV market,It is simple Plug and Play installation.

* bullet 3g sdi camera is a high definition digital video technology that transmits 1080P video quality over coaxial cable,the HD-SDI technology transmits uncompressed video signal to the DVR,HD-SDI camera offer true megapixel image quality.
* miniature bullet 3g sdi camera is a full 3G-SDI / HD-SDI camera that support 1080p 60 or 30fps video format. It is 3G-SDI and HD-SDI international standard compliant. Advanced features include: embedded motion detection, HLC,BLC,WDR,AWB,ATW, private area Mask.
* bullet 3g sdi camera support RS485 protocol
*the camera default protocol is pelco-D

1.Camera

1).Image Device---1/2.8” type SONY CMOS IMX327

2).Scanning System---Progressive Scan

3).Total Pixels---1956(H) x1266(V) : 2.48Mega pixel

4).Effective Pixels---1944(H) x 1092(V) :2.12Mega pixel

5).Lens fitted---Board,

6).Min. Illumination---0.3Lux--F2.5 , 30IRE

7).Sync System---Internal

8).Electronic Shutter---60Hz : 1/30~1/30,000sec,50Hz : 1/25~1/30 000sec

2.Video

1).Output 1---HD-SDI(max. 1080@60p), EX-SDI

2).Output 2(option)---CVBS (NTSC, PAL) without WDR

3).Resolution& Frame rate ---1080@60i/50i, 1080@60p/50p, 1080@30p/25p,

                         720@60p/50p, 720@30p/25p
